Neodyn 182P NEMA 4X, 7, 9 and 13 Vacuum Switch

Neodyn 182P NEMA 4X, 7, 9 and 13 Vacuum Switch: Compact, versatile vacuum switch well suited for hazardous or corrosive atmospheres. For vacuum applications. Features efficient Nega-Rate® Belleville disc spring for stable set points and is field adjustable using a 1/8″ Allen wrench. Once adjustments are made and the switch is installed, it becomes tamper-proof.

Neodyn 182P NEMA 4X, 7, 9 and 13 Vacuum Switch: Compact, versatile vacuum switch well suited for hazardous or corrosive atmospheres. For vacuum applications. Features efficient Nega-Rate® Belleville disc spring for stable set points and is field adjustable using a 1/8″ Allen wrench. Once adjustments are made and the switch is installed, it becomes tamper-proof.

ITT Neo-Dyn® provides a myriad of industrial and aerospace products such as compact adjustable switches, pressure switches, hazardous area switches, vacuum switches, temperature switches & more. Located in Valencia, CA we provide a large selection of process control products for the industrial, chemical & energy markets globally. Our ability to manufacture the highest quality of both commercial & industrial switches in the industry, allows us to give you the most competitive pricing available along with outstanding customer service & fast delivery. If you’d like to learn more, contact us, and our staff can help you!

Features

  • Compact, versatile vacuum switch well suited for hazardous or corrosive atmospheres. For vacuum applications.
  • Features efficient Nega-Rate® Belleville disc spring for stable set points and is field adjustable using a 1/8″ Allen wrench.
  • Once adjustments are made and the switch is installed, it becomes tamper-proof.

Applications

For Industrial Applications

Specifications

  • Electrical: Snap-action electrical switch assembly listed by Underwriters’ Laboratories, Inc., FM Approval, and CSA International
  • Electrical Connection:
  • 1/2 NPT male conduit connection with PVC insulated 18 AWG, 18″ long leads
  • Pressure Connection: 1/4 NPT Male
  • Temperature Range*
    • Ambient: -40°F to +180°F (-40°C to +82°C)
    • Media: -40°F to +300°F (-40°C to +149°C)
  • Adjustment: 1/8″ Allen wrench through port
  • Shipping Weight: Approximately 16 ounces

*Temperature limits change with O-Ring selection. See the Electrical Assembly specification sheet for Temperature Class Ratings.

Downloads

Datasheet : Neodyn 182P NEMA 4X, 7, 9 and 13 Vacuum Switch
