Brainchild CR06 Temperature Chart Recorder

Brainchild CR06 Temperature Chart Recorder offered by Brainchild is a top-quality 6-channel dotting chart recorder designed for maximum flexibility in use and a long life.

Brainchild CR06 Temperature Chart Recorder offered by Brainchild is a top-quality 6-channel dotting chart recorder designed for maximum flexibility in use and a long life. This recorder provides 6-color printing and universal temperature & process inputs. It combines the features of traditional analog chart recorders, and the powers of digital data printing, and is configurable for more than 20 input types. For the permanent recording of parameters, for statutory compliance or quality control, the CR06 will provide a low-cost and convenient solution. Standard RS232 port & IP65 front cover. Consumables are economical and easy to install.

Brainchild CR06 Temperature Chart Recorder Characteristic

It is the dotting style of 6 – a channel chart recorder, universal input, low cost, short depth 150mm, light weight 1.5 kgs and IP65 water-resistance. As a professional and experienced manufacturer, we supply high-performance and quality paperless recorders, video graphic recorders, paperless chart recorders, chart recorders, and temperature chart recorders.

Features

  • 6-channel dotting
  • Short depth in 150mm
  • Weights 1.5kg only
  • Dust-proof.IP-65 Water-resistance
  • Standard RS-232 Communication interface
  • Universal input and range
  • UL, CSA, CE approved
  • 144Wx144Hx150D mm

Applications

It combines the features of traditional analog chart recorders, the powers of digital data printing, and is configurable for more than 20 input types. For permanent recording of parameters, for statutory compliance or quality control, the CR06 will provide a low cost and convenient solution. Standard RS232 port & IP65 front cover. Consumables are economical and easy to install.

Specifications

INPUT
Nos. of input 6
Input sampling 10s/6ch, max
Type of input ±10mV, 0-20mV, 0-50mV, ±1V, 1-5V
Direct ourrent 4-20mA
Thermocouple K, T, J, E,B,S,R,G,C,N,PR40-20, PLII, L, Au-Fe
RTD Pt100, Pt50, JPt100



PERFORMANCE
Accuracy ±0.2%±1 digit max. for Digital indicator/printing
Noise reduction NMRR: 60dB min.
CMRR 140dB min.
Isolation resistance Each terminals/ground: 500VDC, 20MΩ min.
Dielectric strength Power input terminal/ground: 1.5kVAC, 1 minute
Input terminal/ground 0.5kVAC, 1 minute



ALARM
Nos. of relay outputs 6 outs (Form a contacts; Built-in option)
Capacity 30VDC 3A Max. Loaded
COMMUNICATION
Interface RS-232C (Standard), RS-485
POWER SUPPLY
Rated power voltage 100-240VAC (50/60Hz)
Power consumption 25VA max.



STRUCTURE
Mounting/housing Panel mounting/Front panel: Dust-proof,
Water-proof (IP-65)
Dimension 144(W) x 144(H) x 150(D) mm
Weight 1.5kg



OPERATION CONDITION
allowable conditions Temperature: 0-50°C, Humidity: 20-80%



RECORDING / PRINTING PERFORMANCE
Recording Raster-scan printing
Printing Dotting with 6 color ribbon
Dot print interval 10.0s/6ch max.
Chart paper: Length 16m, Dotting width: 100mm
Chart speed User-selective from 28 speed
In range 10-1500mm/hr
Printing color Purple, Red, Green, Blue, Brown, Black
