EGE Opto High Capacity Systems

Here you will find cross section converters to control the edges of bands or detect band interruptions as well as high performance photoelectric barriers and reflex sensors for large distances.

Here you will find cross section converters to control the edges of bands or detect band interruptions as well as high performance photoelectric barriers and reflex sensors for large distances.

Features

  • two fibre-optic cables
  • up to 10 m in length
  • The first fibre-optic cable routes a send signal generated by the amplifier to a first optical converter, while the second fibre-optic cable returns a send signal detected by a second optical converter to the amplifier as a receiving signal.

Applications

  • System description
  • Structure of the Opto Edge controller
  • Recording of cracks, impact or non-homogeneity
  • High capacity amplifier URA 408
  • Universal high capacity amplifier URA 5001
  • Amplifier OKZ 550
  • Fibre-optic cable Amplifier ULL
  • Fibre-optic cable and optical converter
  • Attachment Optics
  • Approval for safety applications

Specifications

The Opto Edge controller consists of an amplifier (1) to which two fibre-optic cables  up to 10 m in length can be connected via a rapid action coupling. The first fibre-optic cable routes a send signal generated by the amplifier to a first optical converter (3), while the second fibre-optic cable returns a send signal detected by a second optical converter (4) to the amplifier as a receiving signal. This receiving signal is processed further in the amplifier into an output control signal.
