Fatek FBs-20MCR2AC PLC Advanced Main Unit design incorporates a “System on Chip” (SoC) developed in-house by Fatek Corporation. The BGA chip consists of over 120,000 gates which integrate powerful features such as a Central Processing Unit (CPU), Memory, Hardware Logic Solver (HLS), 5 high-speed communication ports, 4 sets of hardware high-speed counters/timers, 4 axes of high-speed pulse outputs for NC positioning control (with linear interpolation), 16 high-speed interrupts and captured inputs. The FBsPLC represents high functionality and reliability with exceptional value compared to other PLCs in its class.
PLC & NC Control in one and Dedicated NC
Positioning Language
NC Position Control is incorporated into the SoC of the FBs-PLC which integrates PLC+NC control into one unit in order for resource sharing and reduces the need for data exchange. The NC position control adopts a special positioning command language, which allows programming by mechanical or electrical units and the changing control of parameters during execution. One single unit has up
to four axes outputs with a maximum frequency of 200KHz (MC) or 920KHz (MN)
and equipped with a multi-axis linear interpolation function. If combined with the
four sets of built-in HHSC, it can achieve a fully closed-loop positioning control.
