Tonson M17 G5 Piston Air Motor

Tonson M17 G5 Piston Air Motor TONSON’s patented high precision distinctive radial piston design delivers high torque without high levels of air consumption and air loss as compared to typical vane type air motors.

Tonson M17 G5 Piston Air Motor patented high precision distinctive radial piston design delivers high torque without high levels of air consumption and air loss as compared to typical vane-type air motors. Air Motors are designed to operate by compressed air and to be used with a filter, regulator, and lubricator to improve performance and provide longer life. Air Motors can easily operate under conditions that are unfavorable for electric, hydraulic, stepper, and servo motors.

Features

  • Explosion-proof
  • Stalling Safety
  • Rugged Design
  • Positive Start
  • High Start Torque
  • High Torque output
  • Instantly Reversible
  • Stepless Speed Control
  • Low Air Consumption
  • Easy Maintenance
  • Mounting Flexibility: Flange / Foot / IEC / NEMA / Custom Mounting available
  • Modular Design: All motors may be equipped with gear
  • reducer, brake, hand, remote, remote pendant control as options.
  • Dual-shaft model available.
  • Intrinsically safe in hazardous environment (ex. mines, petrochemical, volatile atmosphere

Applications

  • Hoist / Winches
  • Lifting Devices
  • Mixing Equipment
  • Pump Drives
  • Choppers / Grinders
  • Mining Equipment

Specifications

  • Flange with Brake and Remote Control Valve
  • Type: G5 with Reducer
  • Gear Ratio: 5:1
  • Performance at Maximum Speed
  1. Power (HP): 19
  2. Power (kW): 14.2
  3. Torque: 623 N·m
  4. Torque: 5514 lb·in
  5. Speed: 220 RPM
  6. Air Consumption: 19810 l/min
  7. Air Consumption: 700 CFM
  8. Speed: 44 RPM
  • Maximum Torque
  1. Torque: 1046 N·m
  2. Torque: 9256 lb·in

Downloads

Datasheet : Tonson M17 G5 Piston Air Motor
