Maeda Koki MKT Water Signal Flow Indicator

Maeda Koki MKT Water Signal Flow Indicator, Since this product is using the tube taper form for a transparent tube, it can be used also as a flow rate viewing type of a short form by seeing the related position of a ball and the indicating red line. Since the spring is being used for this product in a transparent tube, the postures when attaching our freedom, such as facing up, facing down, and sideways.

Maeda Koki MKT Water Signal Flow Indicator, Since this product is using the tube taper form for a transparent tube, it can be used also as a flow rate viewing type of a short form by seeing the related position of a ball and the indicating red line. Since the spring is being used for this product in a transparent tube, the postures when attaching our freedom, such as facing up, facing down, and sideways. The heat resistance is 80 ℃. Standard pressure resistance: 1MPa.

Maeda Koki Co., LTD, founded in 1963, Main business: oil signal, water signal, air signal, and flow indicator. We, the current detector using a transparent tube since 1963. The developer, and began its own production

Maeda Koki product, galvanometer for detecting the flow of fluid and galvanometers. In the field of distribution units, new products and technology developed and know-how on past experience. We strive for development. At present, the major companies / influential companies. We have been adopted in response to the tremendous thrust from work.

Features

  • It shows flow quantity by viewing Because it use a transparent taper pipe, MKT can confirm approximate flow quantity by looking at a ball (or a float) and the position with the indication red line concerned.
  • The installation direction does not matter Because it use a spring inside, the posture when it attach it looks up and looks down and can perform sideways-facing freely.

Applications

MKT is a flow indicator, flow switch, and flow control depending on the type. It can confirm approximate flow quality of the water by viewing.

Specifications

Fluid Water
Flow quantity The reference mentioned above When standard specifications flow quantity or less want the above, please refer.
 Connection Rc internal thread Change to R screw
The combination with the R screw is possible, too.
 Heat-resistant temperature A maximum of 80 degrees Celsius
 Withstand pressure 1MPa
Materials Transparent pipe Acrylic
Coupling C3604 (brass) I can produce the product made in SUS, too.
Spring SUS304
Nylon ball Nylon 66 I may use a cylindrical float.
O ring Nitrile rubber

Liast of models

Model Dimensions (mm) Standard specifications flow quantity
(about L/min)
Flow quantity curve list
※Standard specifications
(PDF documents)
Connection diameter Full length Overall width
MKT25-1TW  RC1/8 78 25 1~6
MKT25-2TW Rc1/4 78 25
MKT25-3TW Rc3/8 84 25
MKT30-2TW Rc1/4 104 30 3~20
MKT30-3TW Rc3/8 104 30
MKT30-4TW Rc1/2 110 30

Downloads

Datasheet:Maeda Koki MKT type WATER SIGNAL – Flow Indicator
