Tonson M12 Standard Piston Air Motor

TONSON’s patented high precision distinctive radial piston design delivers high torque without high levels of air consumption and air loss as compared to typical vane type air motors. Air Motors are designed to operate by compressed air and to be used with filter, regulator and lubricator to improve performance and provide longer life. Air Motors can easily operate under conditions which are unfavorable for electric, hydraulic, stepper and servo motors.

Features

  • Explosion-proof
  • Stalling Safety
  • Rugged Design
  • Positive Start
  • High Start Torque
  • High Torque output
  • Instantly Reversible
  • Stepless Speed Control
  • Low Air Consumption
  • Easy Maintenance
  • Mounting Flexibility: Flange / Foot / IEC / NEMA / Custom Mounting available
  • Modular Design: All motors may be equipped with gear
  • reducer, brake, hand, remote, remote pendant control as options.
  • Dual-shaft model available.
  • Intrinsically safe in hazardous environment (ex. mines, petrochemical, volatile atmosphere

Applications

  • Hoist / Winches
  • Lifting Devices
  • Mixing Equipment
  • Pump Drives
  • Choppers / Grinders
  • Mining Equipment

Specifications

  • With Reducer Option
  • Type: Standard
  • Gear Ratio: 1:1
  • Performance at Maximum Speed
  1. Power (HP): 3.31
  2. Power (kW): 2.47
  3. Torque: 17.5 N·m
  4. Torque: 155 lb·in
  5. Speed: 1350 RPM
  6. Air Consumption: 3700 l/min
  7. Air Consumption: 131 CFM
  8. Speed: 270 RPM
  • Maximum Torque
  1. Torque: 31 N·m
  2. Torque: 274 lb·in
