Tonson M13 Standard Piston Air Motor

Tonson M13 Standard Piston Air Motor patented high precision distinctive radial piston design delivers high torque without high levels of air consumption and air loss as compared to typical vane-type air motors. Air Motors are designed to operate by compressed air and to be used with a filter, regulator, and lubricator to improve performance and provide longer life.

Tonson M13 Standard Piston Air Motor

Tonson M13 Standard Piston Air Motor patented high precision distinctive radial piston design delivers high torque without high levels of air consumption and air loss as compared to typical vane-type air motors. Air Motors are designed to operate by compressed air and to be used with a filter, regulator, and lubricator to improve performance and provide longer life. Air Motors can efficiently operate under unfavorable conditions for electric, hydraulic, stepper, and servo motors.

Conditions Including:

  • Very high/low ambient temperatures
  • Radiated heat
  • Powdery/Dust
  • Humid
  • Corrosive
  • Flammable
  • Explosive

Optional Accessories:

  • IEC Flange Or Foot Mount
  • Parking Brake
  • Valve Controls
  • Remote Control valve
  • Hand Control Valve
  • Instant Reversibility
  • Filter – Lubricator – Regulator (FRL)
  • Pressure Gauges
  • Silencers

Features

  • Explosion-proof
  • Stalling Safety
  • Rugged Design
  • Positive Start
  • High Start Torque
  • High Torque output
  • Instantly Reversible
  • Stepless Speed Control
  • Low Air Consumption
  • Easy Maintenance
  • Mounting Flexibility: Flange / Foot / IEC / NEMA / Custom Mounting available
  • Modular Design: All motors may be equipped with gear
  • reducer, brake, hand, remote, remote pendant control as options.
  • Dual-shaft model available.
  • Intrinsically safe in hazardous environment (ex. mines, petrochemical, volatile atmosphere

Applications

  • Hoist / Winches
  • Lifting Devices
  • Mixing Equipment
  • Pump Drives
  • Choppers / Grinders
  • Mining Equipment

Specifications

  • With Flange Option
  • Type: Standard
  • Gear Ratio: 1:1
  • Performance at Maximum Speed
  1. Power (HP): 4.2
  2. Power (kW): 3.09
  3. Torque: 21.6 N·m
  4. Torque: 191 lb·in
  5. Speed: 1350 RPM
  6. Air Consumption: 4200 l/min
  7. Air Consumption: 148 CFM
  8. Speed: 270 RPM
  • Maximum Torque
  1. Torque: 39 N·m
  2. Torque: 345 lb·in

Downloads

Datasheet : Tonson M13 Standard Piston Air Motor
