Tonson M18 G40 Piston Air Motor

Product Note:

No product notes available.

Categories: , Tags: , ,
Contact us

Description

Tonson M18 G40 Piston Air Motor patented high precision distinctive radial piston design delivers high torque without high levels of air consumption and air loss as compared to typical vane-type air motors. Air Motors are designed to operate by compressed air and to be used with a filter, regulator, and lubricator to improve performance and provide longer life. Air Motors can easily operate under conditions that are unfavorable for electric, hydraulic, stepper, and servo motors.

Features

  • Explosion-proof
  • Stalling Safety
  • Rugged Design
  • Positive Start
  • High Start Torque
  • High Torque output
  • Instantly Reversible
  • Stepless Speed Control
  • Low Air Consumption
  • Easy Maintenance
  • Mounting Flexibility: Flange / Foot / IEC / NEMA / Custom Mounting available
  • Modular Design: All motors may be equipped with gear
  • reducer, brake, hand, remote, remote pendant control as options.
  • Dual-shaft model available.
  • Intrinsically safe in hazardous environment (ex. mines, petrochemical, volatile atmosphere

Applications

  • Hoist / Winches
  • Lifting Devices
  • Mixing Equipment
  • Pump Drives
  • Choppers / Grinders
  • Mining Equipment

Specifications

  • Flange with Brake and Control Valve
  • Type: G40 with Brake and Reducer
  • Gear Ratio: 40:1
  • Performance at Maximum Speed
  1. Power (HP): 28.7
  2. Power (kW): 21.4
  3. Torque: 5456 N·m
  4. Torque: 48290 lb·in
  5. Speed: 37.5 RPM
  6. Air Consumption: 22500 l/min
  7. Air Consumption: 795 CFM
  8. Speed: 7.5 RPM
  • Maximum Torque
  1. Torque: 8272 N·m
  2. Torque: 10543 lb·in

Downloads

Datasheet : Tonson M18 G40 Piston Air Motor
