Description

Siko GP43 Geared Potentiometer

Siko GP43 Geared Potentiometer,Potentiometric rotation angle transducers are becoming increasingly important in analog measuring applications requiring high-quality industrial measurement results today due to their excellent cost-benefit ratio.

A Design and functionality of geared potentiometers

A geared potentiometer comprises two main components. One is a measuring gear with precision gear wheels. The other is an electric resistor element with a variable resistance value that is adjusted by turning. The gear unit and potentiometer are assembled at the works with minimum backlash. The integrated slip clutch used in multi-coil potentiometers serves to prevent overrunning of the mechanical stops. A geared potentiometer, therefore, emits an ohmic output signal that is proportional to the number of turns.
