Name: Degson DA004 Insert Male And Female Heavy Duty Connector | onoae
SKU: CDGDA004HDCSET
Price: 210000 IDR
Availability: InStock

Description

Degson DA004 Insert Male and Female are the part of the connector designed to hold the connector contacts in place. Connector inserts and modules are made from a moulded piece of dielectric material that fits inside a connector hood or housing. The insert is therefore the heart of the heavy-duty connector. It is responsible for electrical functioning. Currently, heavy-duty connectors are used wherever there is a need for a secure, simple and time-saving assembly of machinery and facilities.

Degson DA004 Insert Male And Female

Heavy-duty insert
Number of contacts:4+PE
Dimension:4A
Rated voltage:400/230V
Rated current:10A
Male and Female insert
Screw connector

Features

Features INSERT DA-004-:

Model: Insert Male and Female
Number of contacts: 4
Rated current: 10A
Rated voltage conductor-ground: 230V
Rated voltage conductor-conductor: 400V
Rated impulse voltage: 4KV
Pollution degree: 3
Material body: Polycarbonate
Material contact: Copper alloy

Applications

HEAVY-DUTY CONNECTOR APPLICATIONS:
For mechanical and electrical protection in demanding environments, such as in the production machinery, automotive, and energy generation industries, as well as protection in process and control applications.
