Technoton DUT-E S7 Wireless Fuel Level Sensor

Product Note:

No product notes available.

Description

Technoton DUT-E S7 Wireless Fuel Level Sensor

Technoton DUT-E S7 Wireless Fuel Level Sensor DUT-E S7 wireless sensor allows to measure current fuel volume and its changes in a fuel tank. DUT-E S7 is used as a part of vehicle telematics system (GPS vehicle tracking system) and provides reliable information on remaining fuel volume, fuel tank fill-up and draining volumes and helps fleets to set up clear fuel accounting and prevent fuel theft from vehicle’s tank. DUT-E S7 wireless fuel level sensor is also used for fuel level monitoring in stationary tanks.

Wireless data transfer is carried out using S7 Technology via BLE channel. BLE signal from DUT-E S7 can be received by compatible vehicle tracking unit (telematics unit) and/or any Android or iOS device.

DUT-E S7 can also be used as a “night watchman” to alert driver on fuel theft from vehicle’s tank, for example, when resting at night parking.

Features

  • wireless data transfer using S7 Technology via BLE (Bluetooth 4.X Low Energy);
  • operation in BLE-radio mode without pairing with receiver – simultaneous data transfer to telematics unit, smartphones, tablets with Bluetooth
  • built-in battery – DUT-E S7 works without external power supply;
  • very low power consumption allows autonomous operation of sensor within 5…10 years;
  • explosion protection confirmed by “On the Safety of Equipment for Operation in Explosive Environment

Applications

DUT-E S7 can also be used as a “night watchman” to alert driver on fuel theft from vehicle’s tank, for example, when resting at night parking.

Specifications

Estimated lifetime of the sensor (battery life), years5…10*
Fuel level sensor operating principleCapacitive
Wireless data transfer interfaceBluetooth 4.X
Tx Power, dBm+4
Rx sensitivity, dBm-88
Maximum distance between sensor and receiver, m10…20
(when mounted on a vehicle or inside a building)
not less 50
(when mounted within line-of-sight)
Standard probe length, mm700, 1000 (can be manufactured up to 3000 mm on request)
Data transfer interval, s 5
Number of simultaneous BLE-signal receiversAny number in DUT-E S7 operation range
Temperature range, °C-30…+80

*Depending on ambient temperature.

Downloads

Datasheet : Technoton DUT-E S7 Wireless Fuel Level Sensor
