Tonson M16 Standard Piston Air Motor

Product Note:

No product notes available.

Category:

Description

Tonson M16 Standard Piston Air Motor

Tonson M16 Standard Piston Air Motor patent high-precision distinctive radial piston design delivers high torque without high levels of air consumption and air loss as compared to typical vane-type air motors. Air Motors are designed to operate by compressed air and to be used with a filter, regulator, and lubricator to improve performance and provide longer life. Air Motors can easily operate under conditions that are unfavorable for electric, hydraulic, stepper, and servo motors.

Features

  • Explosion-proof
  • Stalling Safety
  • Rugged Design
  • Positive Start
  • High Start Torque
  • High Torque output
  • Instantly Reversible
  • Stepless Speed Control
  • Low Air Consumption
  • Easy Maintenance
  • Mounting Flexibility: Flange / Foot / IEC / NEMA / Custom Mounting available
  • Modular Design: All motors may be equipped with gear
  • reducer, brake, hand, remote, remote pendant control as options.
  • Dual-shaft model available.
  • Intrinsically safe in hazardous environment (ex. mines, petrochemical, volatile atmosphere

Applications

  • Hoist / Winches
  • Lifting Devices
  • Mixing Equipment
  • Pump Drives
  • Choppers / Grinders
  • Mining Equipment

Specifications

  • Foot Type
  • Type: Standard
  • Gear Ratio: 1:1
  • Performance at Maximum Speed
  1. Power (HP): 18.8
  2. Power (kW): 14
  3. Torque: 85 N·m
  4. Torque: 752 lb·in
  5. Speed: 1600 RPM
  6. Air Consumption: 15600 l/min
  7. Air Consumption: 551 CFM
  8. Speed: 320 RPM
  • Maximum Torque
  1. Torque: 140 N·m
  2. Torque: 1239 lb·in

Downloads

Datasheet : Tonson M16 Standard Piston Air Motor
