Features

• ATEX Compliant: All metal components are conductive, allowing electrostatic charges to be safely dissipated to ground.
• Clamped or Bolted Metal Design: Offers leak-free sealing and easy maintenance.
• Maximum Flow: up to 185 gpm (~700 lpm) for the clamped version; approximately 163 gpm (~617 lpm) for the bolted aluminum version
• Maximum Pressure: up to ~125 psi (~8.6 bar) or ~320 ft head (~98 m)
• Port Connections: inlet & outlet 2” NPT; air inlet ½” NPT, exhaust 1” NPT
• Solid Handling Capacity: up to ~6 mm (¼”) solid diameter
• Diaphragm & Ball Valve Material: Buna-N (Nitrile) as standard material
• Suction Lift: dry ~17 ft (5.2 m), wet ~32 ft (9.8 m)
• Operational Noise Level: approximately 94–96 dB(A) depending on material
