Description
Wenglor SA250-P24 Through-Beam Sensor
Wenglor SA250-P24 Through-Beam Sensor these through-beam sensors work in combination with the LV250 controller. They can be freely positioned as desired. Thanks to their large working range, the devices demonstrate excellent functional reliability in highly contaminated environments.
Electrical Data:
- For connection to the LV250 controller
- Functions reliably with severe contamination
- No interactive influence
- Optical Data
- Light Source: Infrared Light
- Service Life (T = +25 °C) : 100000 h
- Opening Angle: 12 °
- Electrical Data
- Sensor Type: Emitter
- Temperature Drift: < 10 %
- Temperature Range : -25…60 °C
- Short Circuit and Overload Protection: yes
- Reverse Polarity Protection: yes
- Protection Class: III
- Mechanical Data
- Housing Material: CuZn, nickel-plated
- Full Encapsulation: yes
- Degree of Protection: IP67
- Connection: Cable, 2-wire, 6 m
- Output
- For connection to LV250 control module: yes
Features at a Glance:
- Functions reliably with severe contamination
- No interactive influence
- For connection to the LV250 controller
