Maeda Koki MKT Air Signal Flow Indicator

Product Note:

No product notes available.

Description

Maeda Koki MKT Air Signal Flow Indicator

Maeda Koki MKT Air Signal Flow Indicator, Since this product is using the tube taper form for a transparent tube, it can be used also as a flow rate viewing type of a short form by seeing the related position of a ball and the indicating red line. Since the spring is being used for this product in a transparent tube, the postures when attaching our freedom, such as facing up, facing down, and sideways. The heat resistance is 80 ?. Standard pressure resistance: 1MPa.

Maeda Koki product, galvanometer for detecting the flow of fluid and galvanometers. In the field of distribution units, new products and technology developed and know-how on past experience. We strive for development. At present, the major companies / influential companies. We have been adopted in response to the tremendous thrust from work.

Features

  • It shows flow quantity by viewing Because it use a transparent taper pipe, MKT can confirm approximate flow quantity by looking at a ball (or a float) and the position with the indication red line concerned.
  • The installation direction does not matter Because it use a spring inside, the posture when it attach it looks up and looks down and can perform sideways-facing freely.

Applications

MKT is a flow indicator, flow switch, and flow control depending on the type. It can confirm approximate flow quality of the water by viewing.

Specifications

FluidGas
ConnectionRc internal threadChange to R screw
The combination with the R screw is possible, too,
 Heat-resistant temperatureA maximum of 80 degrees Celsius
Withstand pressure1MPa
MaterialsTransparent pipeAcrylic
CouplingC3604 (brass)I can produce the product made in SUS, too.
SpringSUS304
Nylon ballNylon 66I may use a cylindrical float.
O ringNitrile rubber





ModelDimensions (mm)Maximum flow quantity
(L/min)
Connection diameterFull lengthOverall width
MKT25-1TARc1/87825200
MKT25-2TARc1/47825200
MKT25-3TARc3/88425200
MKT30-2TARc1/410430500
MKT30-3TARc3/810430500
MKT30-4TARc1/211030500

Downloads

Datasheet: Maeda Koki MKT type AIR SIGNAL – Flow Indicator
